Modern design with consistent accuracy and reproducibility
Motorized control with position compensation module for spectral accuracy and reproducibility
Provides improved reproducibility and accuracy in conjunction with the built-in standard light source.
Automatic calibration via software with interchangeable gratings
Software controlled grating comes with an auto correcting feature. Easily replaceable with magnet-based connector. The mean error <0.2nm.
Uniform information, high transmittance with in-house developed aberration-corrected spectrometer
In house developed aberration-corrected spectrometer delivers highly accurate CCD measurements. (RMS spot radius on the CCD < 10μm)
High speed mapping
and measurement ability
Various advantages can be achieved with our technology, measurement speed of 10ms per maximum spectrum is supported (CCD criteria). MOS2 Raman Mapping receives 2,500 spectrum data points in 58s / 50x50μm / 50x50 pixels.
Total FOV area can be measured with micro level resolution via wide range mapping method
Depending on the stage model maximum measurement area of 75x50mm is supported. Aspirin tablet Raman mapping is measures 250,000 spectrum points with a resolution of 1,500x1,500 micron / 500x500pixels.
